Almost every plumbing repair on this site starts with the same two sentences: shut off the water first, and drain the line. This hub is where that instinct comes from. Water supply lines and the shut-off valves that control them are the plumbing you touch on your way to fixing anything else – and knowing where your main shut-off is, how to isolate a single fixture, and how to swap a supply line without flooding the cabinet is the difference between a five-minute job and a claim on your homeowner’s insurance.

We will show you where your shut-offs live, what actually fails on the supply side, the connection types explained in plain English, and – honestly – the point where soldering, the main line, or a fixture with no accessible shut-off means you stop and call a plumber.

Start Here: Find Your Main Water Shut-Off Before You Need It

The single most valuable plumbing thing you can do this weekend costs nothing: locate your main water shut-off and confirm it turns. When a supply line lets go, you have seconds-to-minutes before real damage, and hunting for the valve in a panic is how a small failure becomes a flooded floor.

Where to look, roughly in order:

• Where the water enters the house. Follow the main line from the water meter toward the building. In a basement or crawl space, the shut-off is usually on that pipe near the foundation wall. On a slab home, look in a utility closet, the garage, or near the water heater.
• Warm climates / no basement. The main is often outside in a meter box at the property line (a curb stop, which is really the utility’s valve) and/or on an exterior wall where the line enters.
• The valve type. A lever ball valve shuts off with a quarter turn (handle across the pipe = closed). An older round gate valve takes several turns clockwise; these seize with age, so test it – a gate valve you cannot turn is itself a reason to have a plumber install a modern ball valve.

This is not folklore. The 2021 International Residential Code (Section P2903.9.1) requires each dwelling unit to be provided with “an accessible main shutoff valve near the entrance of the water service,” of a full-open type, and requires the service to be valved again at the curb or lot line. So in a code-built home two valves exist by design: yours, just inside where the line enters, and the utility’s, out at the property line.

Tag it. Put a bright label or zip-tie tag on the main so anyone in the house can find it, and exercise it once a year so it does not seize. If you are on a well rather than city water, your “off” is also about killing power to the pump and relieving the pressure tank – know both.

Shutting Off Water to a Single Fixture (the Stop Valve)

You rarely need to kill the whole house. Under a toilet, behind a faucet, and at the washing machine there are fixture shut-offs – also called stop valves, angle stops, or supply stops – so you can work on one thing while the rest of the house keeps running.

• Toilet: one stop on the wall (or floor) below the tank, feeding the fill valve.
• Sink/faucet: two stops under the cabinet, hot and cold.
• Washing machine: two stops (or a single lever box) behind the machine.
• Water heater: a shut-off on the cold inlet at the top of the tank.

That list is not arbitrary. The residential code requires a shutoff valve on the fixture supply pipe to each plumbing fixture and appliance other than bathtubs and showers – which is exactly why you will hunt in vain for a handle behind your shower – and it requires those valves to be accessible. It also calls for a readily accessible full-open valve in the cold-water supply pipe to every water heater.

Turn a quarter-turn stop 90 degrees so the handle is across the line; turn an oval-handle multi-turn stop fully clockwise. Then open the fixture to confirm the water actually stopped before you disconnect anything – old stops famously “close” but still weep, which is why a fixture with no working shut-off is a job in itself.

If your home has old multi-turn stops that seize, weep at the packing nut, or will not fully close, replacing them with modern quarter-turn stops is a common upgrade. Whether that is a DIY job depends entirely on how the stop connects to the pipe in the wall – which is the whole point of the connection-types section below.

What Goes Wrong on the Supply Side

Supply-side failures are less about clogs and more about slow leaks, hardening plastic, and worn seals. Roughly in the order homeowners hit them:

• A weeping supply line at a coupling nut – a slow drip where the line meets the fixture or the stop. Usually a loose nut, a bad washer/gasket, or a cross-threaded connection. The cheapest and most common.
• A hardened or cracked plastic riser – old ribbed-plastic and vinyl toilet/faucet lines get brittle and split, sometimes without warning.
• A stop valve that weeps at the stem or will not close – packing worn out on a multi-turn stop, or a seized handle.
• A failed washing-machine hose – old black rubber hoses bulge and burst. The Insurance Institute for Business & Home Safety’s interior-water research ranks interior water damage second only to wind and hail as a driver of homeowner claims, and names the laundry room and its washing-machine plumbing connections among the loss drivers in two-or-more-story homes.
• A leaking compression or threaded joint – under-tightened, over-tightened, or missing thread sealant/PTFE tape on a threaded (not compression) connection.
• A corroded or mineral-crusted fitting – green/white crust at a connection is dissolved metal and mineral; it is telling you a slow leak has been going for a while.
• A push-to-connect fitting that never fully seated – pushed on partway, or onto a pipe that was not cut square and deburred, so it drips or blows off under pressure.
• A pinhole or split in the pipe itself (copper pinholes, a cracked PEX line after a freeze) – this is past “supply line” and into pipe repair, and often a pro job.

One thing worth checking before you blame the part: pressure. The International Plumbing Code caps static pressure inside a building at 80 psi and requires a pressure-reducing valve above that, and the residential code sets the same limit. BrassCraft, meanwhile, rates the G2 quarter-turn angle stop and its universal faucet connector kit at 125 psi maximum and 40 to 160 degrees F. That is headroom, but not much of it – so if you are replacing supply parts more often than seems reasonable, get your house pressure measured before you buy another connector.

Quick triage: where is it leaking?

• Drip at the nut where the line meets the fixture -> snug the nut a little; if it still weeps, replace the washer/gasket or the whole line. Do not just crank it – over-tightening cracks plastic and crushes ferrules.
• Drip at the stop valve stem or handle -> the stop is worn; plan to replace the stop (see the connection section for whether it is DIY).
• The line itself is bulging, crusted, or brittle -> replace it now, do not nurse it. Braided steel is the upgrade.
• Water crust/stain but no active drip you can find -> a past or intermittent leak; dry it, mark it, and watch. Hidden slow leaks are where mold and rot start.

Braided-Steel vs. Plastic Water Supply Lines

For the flexible connectors that run from a stop valve to a fixture, you generally have three tiers:

• Ribbed/vinyl plastic risers – the cheapest, and the ones that harden, crack, and fail with age. Fine short-term, but they are what people are usually replacing after a leak.
• Braided stainless steel – a rubber/PVC core inside a woven stainless jacket. The braid resists bursting and abrasion, they flex to fit, and they are inexpensive. For most toilet, faucet, and washing-machine connections, braided steel is the sensible default and an easy DIY swap.
• Rigid metal risers (chrome-plated brass, copper) – durable and clean-looking but must be bent/cut to fit; more of a finish-plumbing choice than a quick repair.

Two honest caveats: braided steel is not immortal. IBHS describes today’s appliance water connections as flexible plastic hoses “often shrouded with stainless steel braid” and lists their failure modes as normal wear and tear, damage from moving the appliance, too much water pressure, temperature-driven degradation of the rubber and plastic parts, and water quality – not one of which the braid itself prevents. The core still ages, so replace connectors on a sane schedule rather than assuming “steel = forever.” And braided is not the same thing as a reinforced/burst-proof washing-machine hose, which is built for the constant pressure a washer sees; use hoses rated for that job on the washer, and consider a single-lever shut-off box so it is easy to close between loads.

Connection Types, Explained Honestly (and When Each Is Right)

The moment that decides whether a supply or shut-off repair is DIY or pro is how the parts connect. Four types cover almost everything in a house:

Threaded / coupling-nut (the fixture end). The hand-tightened nut where a supply line meets a toilet fill valve or faucet tailpiece uses a built-in rubber washer or cone gasket – no PTFE tape needed on these, and only snug-plus-a-little by hand or with a wrench. This is the most DIY connection there is. BrassCraft’s faucet connector instructions say it plainly: thread the nut onto the faucet shank and “hand tighten only,” go a quarter turn further with a wrench only on a metal nut, and note that because the connector already includes washers, you do not use thread sealant on it. (Tapered pipe threads, like a threaded showerhead or a galvanized fitting, do want PTFE tape – the same manufacturer’s stop-valve instructions, linked below, call for thread sealant on a FIP pipe nipple. Know the difference.)

Compression. A brass nut and a soft brass/ferrule ring that bites onto the pipe to seal – no glue, no heat. Most under-sink stops on copper or CPVC stubs are compression. Homeowner-appropriate for swapping a supply line onto an existing compression stop; replacing the compression stop itself is doable but fussier (the old ferrule often will not come off, and it must reseal correctly). BrassCraft’s water-supply-stop instructions are specific, and the number depends on which end you are making. Installing the stop onto a copper or PEX stub-out: hand-tighten the compression nut as far as it will go, then three-quarters of a turn more with a wrench, keeping the stop square to the tube. Connecting a rigid riser to the stop outlet: 1 to 1-1/4 turns on copper, 1-1/2 to 2 turns on PEX. A flexible braided connector with its own washer is different again – hand tight, or hand tight plus a quarter turn if the nut is metal. Use no putty, gasket material or thread seal tape on a compression joint. Their standing caution is the one that matters most – overtightening, they warn, can crack the product and make it fail long after you walked away. If in doubt, this is a fair line to call.

Push-to-connect (SharkBite and similar). A push-fit fitting with an internal O-ring and grip ring; you cut the pipe clean, deburr it, mark the insertion depth, and push it fully home – no solder, no torch, works on copper, PEX, and CPVC. This is the honest DIY answer to “I need a shut-off but I cannot solder.” It is a legitimate, code-recognized connection: the 2021 IRC (Section P2906.21) permits push-fit fittings on copper-tube-size CPVC, PEX, PE-RT and copper tubing, requires them to conform to ASSE 1061, and requires them to be installed per the manufacturer’s instructions. The failure mode is user error, and BrassCraft’s stop-valve sheet names the errors for you: cut the tube square, round and free of burrs, because if sharp edges are not removed the connection may leak; mark the tube an inch from the end and push the valve at least to that mark, because failing to reach it may result in a leak; and use the fitting with water in exposed locations only. Respect the steps.

PEX (crimp/clamp/expansion). Flexible tubing joined with a crimp ring, cinch clamp, or an expansion fitting. Common in newer homes; each method needs its specific tool, and expansion PEX (e.g., the A-type expander) is a different tool and fitting than crimp PEX. Doable for a handy homeowner who buys the right tool and practices, but it is a step up in commitment.

Soldered / sweated copper. Joints made with a torch, flux, and solder. This is skilled trade work with fire risk near framing and the need to fully drain and dry the line first. For a homeowner, soldering is where the push-to-connect option exists precisely so you do not have to – and where, if a rigid soldered connection is truly required, you call a plumber.

The practical rule: if a repair can be done on the fixture end (coupling nut) or with compression or push-to-connect on an accessible, isolatable line, it is a reasonable DIY. The moment it requires soldering, opening a wall, or touching the main, it is a pro job.

How to Replace a Supply Line (Toilet, Faucet, Washing Machine)

Swapping a flexible supply line is a genuinely DIY task – one of the most satisfying “I fixed it myself” jobs there is – as long as you respect the shut-off-first discipline. The pattern is the same for all three:

1. Close the fixture stop (or the main, if there is no stop). Open the fixture/tap and let the pressure bleed off. This is the step people skip and regret.
2. Have a towel and a small bucket ready. There is always residual water in the line.
3. Loosen the coupling nuts at both ends – one hand bracing the stop or the fixture so you are not torquing the pipe in the wall. Catch the drips.
4. Match the replacement exactly: the end fittings (compression vs. FIP thread), the diameters, and the length – too short strains the joint, too long kinks. Faucet connectors are commonly 3/8 in. compression to 1/2 in. FIP. Fluidmaster’s Click Seal faucet supply lines come in 12, 16, 20 and 30 in. lengths, so measure before you buy. Take the old line to the store or measure carefully.
5. Hand-thread the new nuts first to avoid cross-threading, then snug with a wrench – firm, not gorilla-tight. Braided lines with built-in washers seal on the gasket, not on brute force.
6. Open the stop slowly and inspect both connections for a full minute. Then check again in an hour, and again the next day. A weep now is a flood later.

Toilet and faucet lines are the friendliest; washing-machine hoses are the highest-value because old rubber ones are a top water-damage source – replace both, use burst-resistant braided hoses, and close the box between uses if you can.

Tools You’ll Actually Need

• An adjustable wrench and channel-lock pliers – for coupling nuts and stops.
• A towel and a small bucket – non-negotiable for supply work.
• PTFE (plumber’s) tape – for tapered pipe threads only, not for washered coupling nuts.
• A tubing/pipe cutter and a deburring tool – if you go the push-to-connect or PEX route (a clean, square, deburred cut is what makes those fittings seal).
• A push-to-connect disconnect clip – if you use SharkBite-style fittings and may need to remove one.
• The correct PEX tool – only if you are working in PEX (crimp, cinch, or expansion – they are not interchangeable).

DIY vs. Call a Pro: The Honest Line

Most supply-line work is squarely DIY: replacing a flexible connector, swapping to a quarter-turn stop on an accessible compression or push-to-connect line, and changing washing-machine hoses. Our DIY value study is built on exactly this idea – the highest-return home repairs are the low-risk, high-frequency ones, and supply lines are the textbook case.

Call a licensed plumber when:

• The connection needs soldering and a push-to-connect alternative is not appropriate. Torch work near framing, with the line fully drained and dried, is trade work.
• The repair is on the main line – the main shut-off, the meter side, or the line between the meter and the house. Get this wrong and you are flooding at full house pressure.
• There is no accessible or working shut-off to isolate the fixture. If you cannot stop the water, you cannot safely work – and installing a stop where none exists (or the stop is soldered/seized) is a pro job.
• The pipe itself has failed – a copper pinhole, a split from freezing, or a joint inside a wall. That is pipe repair, not a supply-line swap.
• You see signs of hidden, long-running leakage – staining on a ceiling below, soft flooring, or persistent dampness. Finding and fixing that safely often means opening things up.
• Anything gas. If you are near a water heater, note that its cold-water supply line and shut-off are DIY-adjacent, but the gas connection, the T&P (temperature and pressure relief) valve, the flue, and the burner are not. Genuinely safe water-heater DIY is limited to draining/flushing sediment, checking the anode rod, setting the thermostat, and visual diagnosis; the gas, electrical, scald, and carbon-monoxide hazards make the rest pro territory. When in doubt at the heater, stop.

There is no prize for improvising a shut-off or soldering over your head. The flexible lines, the fixture connections, and accessible stops are yours; the main, the wall, the torch, and the gas are the plumber’s. For a sense of what the pro side runs, see our plumbing repair cost study.

Where to Go From Here

This hub is the foundation the rest of the site links back to. The step-by-step spoke guides below publish over the coming weeks; in the meantime, the fixture hubs cover the repairs that begin with shutting off the water:

• Faucet drips and cartridges: the faucet repair guide (and identify your exact part with the free faucet cartridge finder).
• Running or leaking toilets: the toilet repair guide – where a hardened toilet supply line and a weeping stop show up constantly.
• Slow or clogged drains: the drain repair guide.
• Drips, pressure, and temperature at the shower: the shower repair guide.

And to judge what is worth doing yourself versus hiring out, the plumbing DIY value study and the plumbing repair cost study put real numbers behind the honest line above.

---

This supply lines and shut-offs guide is for general homeowner education and is not a substitute for licensed professional advice. Local plumbing codes vary by jurisdiction. When a repair involves soldering, the main water line, a fixture with no accessible shut-off, a failed pipe inside a wall, or any gas connection at a water heater, consult a licensed plumber.
